Roxtec CM modules are 30 mm (1.181") deep and easily adapted to cables and pipes of different sizes. When used with a solid core, the module functions as a spare module for future capacity.
- To be used with corresponding Roxtec components to form a complete sealing solution
- For cables and pipes 3.5-54 mm (0.138"-2.125") OD
Technical drawings
Variants
CM 40 10-32
- External dimensions WxHxD (mm) 40 x 40 x 30
- Number of cables/pipes 1
- For cable/pipe Ø (mm) 9.5 - 32.5
- Weight (kg) 0.07
- Art. No C000140101000
CM 60 0+24-54
- External dimensions WxHxD (mm) 60 x 60 x 30
- Number of cables/pipes 1
- For cable/pipe Ø (mm) 24 - 54
- Weight (kg) 0.16
- Art. No 5C00000001208
